Progress in the application of 4,4′-diaminodiphenylmethane in the preparation of modified epoxy resins

Progress in the Application of 4,4′-Diaminodiphenylmethane in the Preparation of Modified Epoxy Resins

Abstract: Epoxy resins, renowned for their exceptional mechanical strength, chemical resistance, and adhesive properties, find extensive applications across diverse industries. However, inherent limitations such as brittleness, low impact strength, and susceptibility to micro-cracking often necessitate modification to tailor their performance for specific applications. 4,4′-Diaminodiphenylmethane (DDM), a widely used aromatic diamine curing agent, plays a crucial role in the preparation of epoxy resins. This review delves into the recent advancements in utilizing DDM as a modifier or co-curing agent to enhance the properties of epoxy resins. We explore various modification strategies, including the incorporation of DDM with other curing agents, the development of DDM-based epoxy adducts, and the utilization of DDM in nanocomposite formulations. We further analyze the resulting product parameters, focusing on the improvements achieved in mechanical properties, thermal stability, and other key performance characteristics. This review provides a comprehensive overview of the current state of research and development in DDM-modified epoxy resins, highlighting the potential for future advancements in this field.

Keywords: Epoxy Resin, 4,4′-Diaminodiphenylmethane (DDM), Curing Agent, Modification, Mechanical Properties, Thermal Stability, Nanocomposites.

1. Introduction

Epoxy resins are a class of thermosetting polymers characterized by the presence of epoxide groups (oxirane rings). Their exceptional properties, including high adhesive strength, superior electrical insulation, excellent chemical resistance, and dimensional stability, make them invaluable in various applications, ranging from coatings and adhesives to structural composites and electronic encapsulation [1, 2]. Despite these advantages, unmodified epoxy resins often exhibit limitations such as brittleness, low impact resistance, and a tendency to crack propagation, particularly under harsh environmental conditions [3, 4]. These shortcomings hinder their widespread adoption in demanding applications.

To overcome these limitations, various modification strategies have been developed to tailor the properties of epoxy resins to meet specific requirements. These strategies include the incorporation of toughening agents, the use of reactive diluents, the blending with other polymers, and the modification of the curing process [5, 6]. Among the crucial components in the epoxy resin formulation is the curing agent, which initiates the crosslinking reaction and ultimately determines the final properties of the cured resin.

4,4′-Diaminodiphenylmethane (DDM), also known as methylene dianiline (MDA), is a widely used aromatic diamine curing agent for epoxy resins. Its relatively high reactivity, good thermal stability, and ability to form rigid crosslinked networks make it a preferred choice in numerous applications [7, 8]. However, concerns regarding its toxicity and potential carcinogenicity have spurred research into alternative curing agents or modification strategies to mitigate these risks [9].

This review focuses on the recent progress in utilizing DDM as a modifier or co-curing agent to enhance the properties of epoxy resins. We explore various modification techniques, including the combination of DDM with other curing agents, the creation of DDM-based epoxy adducts, and the incorporation of DDM in nanocomposite formulations. The review also analyzes the resulting product parameters, focusing on the improvements achieved in mechanical properties, thermal stability, and other key performance characteristics.

2. DDM as a Curing Agent for Epoxy Resins: Fundamentals

DDM is an aromatic diamine with the chemical formula C₁₃H₁₄N₂. It consists of two aniline rings connected by a methylene bridge. The two primary amine groups (-NH₂) on each aniline ring are responsible for reacting with the epoxide groups of the epoxy resin during the curing process [10]. The reaction between DDM and epoxy resin is an addition polymerization, where the amine groups of DDM open the epoxide rings, forming a three-dimensional crosslinked network [11].

The curing process is influenced by several factors, including the stoichiometry of the epoxy resin and DDM, the curing temperature, and the presence of catalysts. Typically, a stoichiometric ratio of one amine hydrogen equivalent to one epoxide equivalent is used to achieve optimal crosslinking [12]. The curing temperature affects the reaction rate and the degree of crosslinking. Higher curing temperatures generally lead to faster reaction rates and a higher degree of crosslinking, but can also induce degradation or thermal stresses in the cured resin [13]. Catalysts, such as tertiary amines or imidazoles, can be used to accelerate the curing reaction and reduce the curing temperature [14].

The structure of the cured epoxy resin network is determined by the molecular structure of the epoxy resin and the curing agent, as well as the curing conditions. DDM, with its rigid aromatic structure, contributes to the high glass transition temperature (Tg) and good thermal stability of the cured epoxy resin. However, the high crosslink density resulting from the use of DDM can also lead to brittleness and low impact resistance [15].

3. Modification Strategies Involving DDM

To overcome the limitations of DDM-cured epoxy resins, several modification strategies have been developed. These strategies aim to improve the mechanical properties, thermal stability, and other performance characteristics of the cured resin while mitigating the potential risks associated with DDM.

3.1. Co-Curing with Other Curing Agents

One approach to modifying DDM-cured epoxy resins is to use DDM in combination with other curing agents. This allows for tailoring the properties of the cured resin by leveraging the advantages of different curing agents.

• Aliphatic Amines: Aliphatic amines, such as triethylenetetramine (TETA) and diethylenetriamine (DETA), are known for their high reactivity and ability to cure epoxy resins at room temperature. However, they often result in lower Tg and poorer thermal stability compared to DDM. By co-curing DDM with aliphatic amines, it is possible to achieve a balance between reactivity and thermal stability [16]. For instance, the addition of TETA to a DDM-cured epoxy resin can improve the cure speed and reduce the cure temperature while maintaining a relatively high Tg.

• Anhydrides: Anhydrides, such as methyltetrahydrophthalic anhydride (MTHPA) and hexahydrophthalic anhydride (HHPA), are latent curing agents that require elevated temperatures to initiate the curing reaction. Anhydride-cured epoxy resins typically exhibit excellent electrical properties and chemical resistance. Co-curing DDM with anhydrides can improve the mechanical properties and reduce the cure time compared to using anhydrides alone [17]. The addition of DDM can act as a catalyst for the anhydride curing reaction, leading to a faster cure rate and a higher degree of crosslinking.

• Polyamidoamines: Polyamidoamines are derived from the reaction of polyamines with fatty acids. They offer improved flexibility and toughness compared to DDM. Co-curing DDM with polyamidoamines can enhance the impact resistance and crack resistance of the cured epoxy resin [18]. The polyamidoamine acts as a toughening agent, reducing the brittleness associated with the DDM-cured epoxy resin.

Table 1: Effect of Co-Curing Agents on Epoxy Resin Properties

3.2. DDM-Based Epoxy Adducts

Another modification strategy involves the pre-reaction of DDM with epoxy resin to form epoxy adducts. These adducts can then be used as curing agents for further crosslinking of the epoxy resin. This approach allows for controlling the reactivity and compatibility of DDM with the epoxy resin, leading to improved properties in the cured resin.

• Epoxy-Amine Adducts: Epoxy-amine adducts are formed by reacting DDM with a stoichiometric excess of epoxy resin. This reaction results in the formation of amine-terminated oligomers with epoxy groups at the chain ends. These adducts can be used as curing agents for epoxy resins, providing improved flexibility and toughness compared to using DDM directly [19]. The pre-reaction of DDM with epoxy resin reduces the concentration of free DDM, mitigating potential toxicity concerns.

• DDM-Modified Novolac Resins: Novolac resins are phenolic resins that can be modified with DDM to improve their thermal stability and mechanical properties. The reaction of DDM with novolac resin results in the formation of a complex network structure with enhanced crosslinking density [20]. These DDM-modified novolac resins can be used as curing agents for epoxy resins, providing improved heat resistance and dimensional stability.

Table 2: Properties of DDM-Based Epoxy Adducts

3.3. DDM in Nanocomposite Formulations

The incorporation of nanofillers into epoxy resins can significantly enhance their mechanical, thermal, and electrical properties. DDM plays a crucial role in the curing process of these nanocomposites, ensuring proper dispersion and interfacial adhesion between the nanofillers and the epoxy matrix.

• Carbon Nanotubes (CNTs): CNTs are known for their exceptional strength, stiffness, and electrical conductivity. The addition of CNTs to epoxy resins can significantly improve their mechanical properties and electrical conductivity. DDM facilitates the dispersion of CNTs in the epoxy matrix and promotes interfacial adhesion between the CNTs and the epoxy resin [21]. The amine groups of DDM can react with functional groups on the surface of the CNTs, leading to improved bonding and load transfer.

• Graphene Oxide (GO): GO is a two-dimensional material with a large surface area and abundant functional groups. The addition of GO to epoxy resins can improve their mechanical properties, thermal stability, and barrier properties. DDM acts as a curing agent and a compatibilizer, promoting the dispersion of GO in the epoxy matrix and enhancing interfacial adhesion [22]. The amine groups of DDM can react with the epoxy groups on the GO surface, leading to covalent bonding and improved stress transfer.

• Silica Nanoparticles (SiO₂): Silica nanoparticles are commonly used to improve the mechanical properties and scratch resistance of epoxy coatings. The addition of silica nanoparticles to epoxy resins can increase their hardness, modulus, and abrasion resistance. DDM facilitates the dispersion of silica nanoparticles in the epoxy matrix and enhances interfacial adhesion [23]. The amine groups of DDM can react with silanol groups on the surface of the silica nanoparticles, leading to improved bonding and a more homogeneous nanocomposite.

Table 3: Effect of DDM in Epoxy Nanocomposites

4. Product Parameters and Performance Characteristics

The modification strategies involving DDM significantly impact the properties and performance characteristics of the cured epoxy resins. This section analyzes the resulting product parameters, focusing on mechanical properties, thermal stability, and other key performance characteristics.

4.1. Mechanical Properties

The mechanical properties of epoxy resins, such as tensile strength, tensile modulus, flexural strength, flexural modulus, impact strength, and fracture toughness, are crucial for their structural applications. The modification strategies involving DDM can significantly improve these properties.

• Tensile Strength and Modulus: Co-curing DDM with other curing agents, such as polyamidoamines, can improve the tensile strength and modulus of the cured epoxy resin. The polyamidoamine acts as a toughening agent, reducing the stress concentration at crack tips and increasing the resistance to tensile deformation. The incorporation of nanofillers, such as CNTs and GO, can also significantly enhance the tensile strength and modulus of the epoxy resin.

• Impact Strength and Fracture Toughness: The impact strength and fracture toughness are critical for applications where the epoxy resin is subjected to impact loading or cyclic stresses. The addition of toughening agents, such as rubber particles or core-shell particles, can significantly improve the impact strength and fracture toughness of DDM-cured epoxy resins. Co-curing DDM with polyamidoamines can also enhance these properties. The incorporation of nanofillers, such as CNTs and GO, can further improve the impact strength and fracture toughness by bridging cracks and preventing their propagation.

Table 4: Effect of Modification on Mechanical Properties

4.2. Thermal Stability

The thermal stability of epoxy resins, as measured by the glass transition temperature (Tg) and the thermal decomposition temperature (TGA), is crucial for applications where the resin is exposed to elevated temperatures. DDM-cured epoxy resins generally exhibit good thermal stability due to the rigid aromatic structure of DDM. However, modification strategies can further enhance the thermal stability of the cured resin.

• Glass Transition Temperature (Tg): Co-curing DDM with anhydrides or using DDM-modified novolac resins can increase the Tg of the cured epoxy resin. The increased crosslinking density and the presence of rigid aromatic structures contribute to the higher Tg. The incorporation of nanofillers, such as silica nanoparticles, can also improve the Tg of the epoxy resin by restricting the segmental mobility of the polymer chains.

• Thermal Decomposition Temperature (TGA): The thermal decomposition temperature (TGA) measures the resistance of the epoxy resin to thermal degradation. The incorporation of nanofillers, such as CNTs and GO, can significantly improve the TGA of the epoxy resin by acting as a barrier to the diffusion of volatile degradation products.

Table 5: Effect of Modification on Thermal Stability

4.3. Other Performance Characteristics

Besides mechanical properties and thermal stability, other performance characteristics, such as chemical resistance, electrical properties, and adhesive strength, are also important for various applications.

• Chemical Resistance: DDM-cured epoxy resins generally exhibit good chemical resistance to a wide range of solvents and chemicals. Modification strategies, such as the incorporation of nanofillers, can further enhance the chemical resistance of the cured resin by reducing the permeability of the epoxy matrix.

• Electrical Properties: Epoxy resins are excellent electrical insulators. Modification strategies, such as the addition of conductive nanofillers (e.g., CNTs), can tailor the electrical conductivity of the epoxy resin for specific applications.

• Adhesive Strength: DDM-cured epoxy resins are widely used as adhesives due to their high adhesive strength. Modification strategies, such as the incorporation of silane coupling agents, can improve the adhesion of the epoxy resin to various substrates.

5. Future Trends and Perspectives

The research and development of DDM-modified epoxy resins continue to evolve, driven by the demand for high-performance materials with tailored properties. Future trends and perspectives in this field include:

• Development of Bio-Based DDM Alternatives: Concerns regarding the toxicity and environmental impact of DDM have spurred research into bio-based alternatives. Developing bio-based diamines with comparable reactivity and performance is a promising area of research.
• Advanced Nanocomposite Formulations: Utilizing advanced nanofillers, such as functionalized CNTs and graphene derivatives, can further enhance the properties of DDM-modified epoxy nanocomposites.
• 3D Printing of DDM-Modified Epoxy Resins: 3D printing (additive manufacturing) offers the possibility of creating complex shapes and customized structures using epoxy resins. Developing DDM-modified epoxy resins suitable for 3D printing is an emerging area of research.
• Self-Healing Epoxy Resins: Incorporating self-healing mechanisms into DDM-modified epoxy resins can extend their service life and reduce maintenance costs. This involves incorporating microcapsules containing healing agents or utilizing reversible chemical bonds.

6. Conclusion

4,4′-Diaminodiphenylmethane (DDM) remains a crucial curing agent for epoxy resins due to its ability to form rigid crosslinked networks with excellent thermal stability. However, its inherent brittleness and potential toxicity necessitate modification to tailor its performance for specific applications. This review has explored various modification strategies, including co-curing with other curing agents, the development of DDM-based epoxy adducts, and the utilization of DDM in nanocomposite formulations. These strategies offer significant improvements in mechanical properties, thermal stability, and other key performance characteristics. Further research and development in bio-based alternatives, advanced nanocomposite formulations, 3D printing, and self-healing mechanisms will continue to expand the applications of DDM-modified epoxy resins in diverse industries.

References:

[1] Ellis, B. (1993). Chemistry and Technology of Epoxy Resins. Springer Science & Business Media.

[2] Iqbal, A., et al. (2020). A comprehensive review of epoxy resin composites. Polymer Composites, 41(12), 4827-4864.

[3] Kinloch, A. J. (2005). Fracture behaviour of epoxy resins. Advanced Polymer Science, 182, 1-55.

[4] Pritchard, G. (2012). Epoxy Resins: Chemistry and Technology. Springer Science & Business Media.

[5] Riew, C. K., Rowe, E. H., & Siebert, A. R. (1976). Rubber modified thermosets. ACS Advances in Chemistry Series, 154, 326-344.

[6] Sultan, J. N., & McGarry, F. J. (1973). Fracture of epoxy resins modified with particulate fillers. Polymer Engineering & Science, 13(1), 29-34.

[7] Lee, H., & Neville, K. (1967). Handbook of Epoxy Resins. McGraw-Hill.

[8] May, C. A. (1988). Epoxy Resins: Chemistry and Technology. Marcel Dekker.

[9] Dearfield, K. L., et al. (1991). Genotoxicity risk assessment of 4,4′-methylenedianiline (MDA). Mutation Research/Reviews in Genetic Toxicology, 259(3), 221-245.

[10] Smith, J. G. (2011). Organic Chemistry. McGraw-Hill.

[11] Pascault, J. P., & Williams, R. J. J. (2010). Epoxy Polymers: Chemistry and Technology. Wiley-VCH.

[12] Prime, R. B. (1999). Thermosets: Structure, Properties, and Applications. ASM International.

[13] Mijovic, J., & Wijaya, J. (2002). The glass transition temperature of epoxy networks. Polymer, 43(17), 4811-4818.

[14] Riccardi, C. C., Adabbo, H. E., & Williams, R. J. J. (1984). Curing reactions of epoxy resins with aromatic diamines. Journal of Applied Polymer Science, 29(1), 113-123.

[15] Ratna, D. (2013). Handbook of Thermoset Resins. Smithers Rapra Publishing.

[16] Wang, X., et al. (2015). Influence of aliphatic amine curing agents on the properties of epoxy resins. Journal of Applied Polymer Science, 132(4), 41414.

[17] Zhang, Y., et al. (2018). Toughening of epoxy resins with anhydride curing agents. Polymer Engineering & Science, 58(S1), E387-E395.

[18] Liu, J., et al. (2019). Polyamidoamine as a toughening agent for epoxy resins. Journal of Polymer Science Part B: Polymer Physics, 57(14), 917-925.

[19] Chen, S., et al. (2012). Synthesis and characterization of epoxy-amine adducts as curing agents for epoxy resins. Polymer, 53(26), 5991-5999.

[20] Tanaka, Y. (1970). Synthesis and properties of epoxy resins cured with novolacs. Journal of Polymer Science Part A-1: Polymer Chemistry, 8(10), 2757-2770.

[21] Spitalsky, Z., Tasis, D., Papagelis, K., & Galiotis, C. (2010). Carbon nanotube–polymer single composite mechanical properties: A review. Progress in Polymer Science, 35(3), 357-401.

[22] Rafiee, M. A., Rafiee, J., Wang, Z., Song, H., Yu, Z. Z., & Koratkar, N. (2010). Enhanced mechanical properties of nanocomposites at low graphene content. ACS Nano, 4(6), 3169-3176.

[23] Bharadwaj, R. K. (2001). Mechanical properties of polymer nanocomposites. Macromolecular Materials and Engineering, 286(2), 89-106.
